Ring Automotive

RINVPA6/REINVPA6 PowerSourcePure Pure Sine Inverter

PowerSourcePure Pure Sine Inverter

600W

12V DC

Professional 600 watt pure sine wave inverter, converts 12 volt battery power into useful 230 volt AC mains power - ideal for remote applications such as service vehicles. Pure sine wave inverters provide an extremely pure output, which replicates the normal domestic mains supply. This makes them suitable for powering products not compatible with modified sine wave inverters, such as certain power tools, coffee machines, laser printers and sensitive electronics such as laptops and audio/visual equipment.

Highly efficient, running at 90% efficiency at 75% load, and with minimal footprint to reduce installation space. Includes a power saving mode to reduce battery drain when not in use. All models are fully protected against overload, over temperature and low/high voltages.

An additional LCD screen is also available, to provide power consumption information – essential for effective power management when working remotely. Also available is the RINVCM Current Sensor, which monitors the inverter's battery current, allowing indication of time remaining before battery is flat to help improve power management.

PowerSourcePure inverters are E-Marked and tested and certified to the relevant EMC and LVD Directives.

For Ring's full range of commercial inverters and accessories, click here

  • 600W pure sine wave inverter
  • Operating mode and fault indicators
  • Power saving mode reduces standby power
  • Up to 12 hours continuous use
  • Compact heavy duty extruded casing
  • USB charging socket for mobile devices
  • Optional multi-function LCD display (RINVLCD)
  • Optional battery sensor module (RINVCM)
  • Fully protected against overload, over temperature and low/high voltage
  • Suitable for 12V vehicles
Product dimensions (mm): HxWxD
85 x 171 x 383
Weight (kg)
3.418
Voltage
12V DC Input 230V AC Output
Wattage
600W
E Regulation
10 - EMC
Continuous power rating (up to 12hrs)
600W
Surge power rating (up to 200msc)
1200W
Output voltage
Adjustable: 200/220/230/240V +/- 10%
Output frequency
Adjustable: 50/60 Hz
Output waveform
600W
Input voltage range
9.5V - 16.5V (12V nom)
Efficiency at 75% load
90%
No load current draw
<1.5A
Power saving mode
Yes
Power saving mode current
<0.2A
Low battery alarm sounds
10.0V - 11.5V +/- 0.5V
Low battery shut down
9.5V - 11V +/- 0.5V
Thermal protection
60 +/1 10°C
USB
2.1A

Available as

BOX - SINGLE
Code: RINVPA6

BOX - SINGLE
